Features:
-
Integrated Control Unit & Virtual Encoder: Ensures smooth operation with advanced movement tracking and torque management.
-
Switching Power Supply (115/230 Vac): Reduces energy consumption while extending the actuator’s lifespan.
-
Easy Wiring Access: The main control unit is positioned on the top part of the motor for simplified wiring.
-
Virtual Encoder System: Manages slowing-down phases and provides precise movement tracking, ensuring maximum safety with STC (Soft Touch Control) system.
-
Self-Programming: Can be programmed with the radio transmitter during the first installation.
-
Practical Cable Guides: For organized and protected wiring.
-
High Performance & Speed: Operates at a speed of 25.5 m/min, suitable for gates up to 600 kg.
-
Anti-Crushing System: Equipped with amperometric obstacle detection to prevent accidents.
-
Safety Sensor: Automatically cuts off the motor’s power supply during release operations for added safety.
-
KNX Domotics Integration: Compatible with the X.BE accessory for seamless integration with home automation systems, and programmable via the BeUP app and PRO.UP interface.
-
Backup Power: Operates on integrated batteries in case of power failure, ensuring continued operation.
-
Opposed Sliding Gates: Supports the SIS accessory for operating two sliding gates in opposition.
The BULL 624 TURBO is engineered for durability and reliability, with a focus on delivering consistent performance and ease of maintenance. It offers a practical solution for automating sliding gates with a balance of advanced features and robust construction.
Power supply 115 Vac / 230 Vac (50-60Hz)
Motor supply 24 Vdc
Max absorbed current 5 / 3 A
Maximum thrust 330 N
Opening speed 12,5 ÷ 25,5 m/min
Duty cycle 60%
Protection level IP44
Built-in control unit
Integrated receiver
Encoder
Virtual encoder
Magnetic limit switches
Pinion for rack M4 Z18
Operating temperature -20°C /+50°C
Lubrication GREASE
Maximum gate weight 600 kg
Weight 10 kg
